Industry leading high brightness, high light efficacy
Higher center illumination, high power density
Standard package size, suitable for universal lens, drive
Advanced technology and digital manufacturing system, quality assurance
| Product Code | Size (mm) | LES (mm) | Chip quantity | CCT (K) | CRI | MAX Power (W) | VF (V) | MAX IF (mA) | Typical IF (mA) | Luminous Flux (lm) | (Im/w) | Colorimetric standard | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Typical | Min-Max | |||||||||||||
| HTK-D3535H-007-0101A4070SP | 3.5*3.5*2.6 | 1.65*1.65 | 1 | 4000 | 70 | 7 | 2.8 | 2000 | 700 | 370 | 330-400 | 185 | ANSI | 3/5-Step oval |
| HTK-D3535H-007-0101A5070SP | 5000 | 370 | 330-400 | 185 | ||||||||||
| HTK-D3535H-005-0101A5770SP | 5700 | 350 | 310-380 | 175 | ||||||||||
| HTK-D3535H-005-0101A6570SP | 6500 | 350 | 310-380 | 175 | ||||||||||
| HTK-D3535H-007-0101A2780SH | 3.5*3.5*2.6 | 1.65*1.65 | 1 | 2700 | 80 | 7 | 2.8 | 2000 | 700 | 275 | 250-310 | 135 | ANSI | 5-step 分bin |
| HTK-D3535H-007-0101A3080SH | 3000 | 285 | 255-315 | 140 | ||||||||||
| HTK-D3535H-007-0101A3580SH | 3500 | 300 | 270-340 | 150 | ||||||||||
| HTK-D3535H-007-0101A4080SH | 4000 | 320 | 280-350 | 160 | ||||||||||
| HTK-D3535H-007-0101A2790SH | 3.5*3.5*2.6 | 1.65*1.65 | 1 | 2700 | 90 | 7 | 2.8 | 2000 | 700 | 250 | 220-280 | 125 | ANSI | 5-step 分bin |
| HTK-D3535H-007-0101A3090SH | 3000 | 260 | 230-290 | 130 | ||||||||||
| HTK-D3535H-007-0101A3590SH | 3500 | 270 | 240-300 | 135 | ||||||||||
| HTK-D3535H-007-0101A4090SH | 4000 | 290 | 260-320 | 145 | ||||||||||
